Blue Sea 7035 187 - Series Thermal Circuit Breaker - 25Amp

187 - Series Thermal Circuit Breakers - Panel Mount25 Amp Circuit BreakerPN: 7035Features:

• Combines switching and circuit protection into a single device
• All components meet SAE J1171 external ignition protection requirements
• Clear, single lever operation
• "Trip Free" design cannot be held "ON" during fault current condition
• Waterproof
• Recessed mounting holes for clean appearance
• Self-trimming case eliminates the need for mounting panels or trim bezels
• Round case permits easy installation with standard sized hole saw
• Large clearance around terminal studs accept heavy gauge wire lugs
• Robust 5/16 terminals provide high torque connections
• Large lever with vertical/horizontal orientation provides indication of trip status
• Ignition protected - safe for installation aboard gasoline powered boats

Specifications Circuit Breaker Class:Type III - Switchable / Manual Reset - Trip FreeType:Thermally Responsive Bi-Metal BladeCase Material:Thermoset PolyesterVoltage Rating:48 Volts DC MaximumInterrupt Rating:5,000 Amperes @12 Volts DC 3,000 Amperes @24 Volts DC 1,500 Amperes @42 Volts DCOperating Temperature Range:-25C° to +82C°

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Combines circuit protection and switching into a single device with clear, single-lever operation."Trip Free" design prevents holding the switch "ON" during fault conditions for added safety.Waterproof construction with recessed mounting holes ensures a clean appearance.Large clearance around terminal studs accommodates heavy-gauge wire lugs; robust 5/16 M8 terminals provide secure, high-torque connections.Large lever with vertical/horizontal orientation indicates trip status, while ignition protection ensures safe installation aboard gasoline-powered boats.
