Blue Sea 7765 L-Series Solenoid Switch - 50A - 12/24V DC

7765 L-Series Solenoid Switch - 50A - 12/24V DC

Ideal for switching DC subpanels, thrusters, windlass, inverters, and other medium-amp DC loads.

Features:

• Continuous duty, SPST - Normally Open
• Hermetically sealed contacts
• Activated by a remote ON-OFF switch 8230 (sold separately)
• Coil control circuit minimizes heating and amperage draw

Control Circuit Connection: 22 AWG tinned wire, Contact Voltage: 320V DC, Max Voltage: 320V DC, Amperage Operating Current Continuous: 0.13A @ 12 V & 0.07A @ 24 V, Amperage Operating Current when changing state: 3.8A, Terminal Stud: M8 (accepts 5/16" terminals), Terminal Stud Torque: 90 in-lb (10.17 Nm) max, Control Circuit Voltage: 9-36V DC (12/24V nominal), Continuous Rating: 150A, Intermittent Rating: 225A (5 min), Cranking Rating 30 sec: 600A, Contact Form: SPST-NOContinuous duty, SPST - Normally OpenHermetically sealed contactsActivated by a low amperage ON-OFF switch mounted anywhereCoil control circuit minimizes heating and amperage drawNo external coil supression requiredRated IP67
